Key Features
High Torque Capacity
Torque Range: 200–1000 Nm (148–738 ft·lb)
Designed to handle high-torque tightening applications with ease, ideal for industrial assembly, heavy equipment, and maintenance tasks.
Click-Type Mechanism
Provides a clear audible and tactile “click” when the set torque is reached.
Ensures accurate and repeatable tightening without over-torquing.
Rugged 1” Drive Square
Equipped with a 1-inch square drive, compatible with large sockets commonly used in high-torque applications.
Supports demanding jobs in transportation, construction, and energy sectors.
Precision Accuracy
Accuracy of ±4%, compliant with EN ISO 6789-1:2017 standards.
Delivers reliable results for consistent process control in non-critical bolting applications.
Industrial-Grade Build
Heavy-duty construction with a strong ratchet mechanism and robust metal components.
Built to withstand daily use in tough working environments.
Ergonomic & Extended Reach
Length: 1224 mm, providing leverage needed for high-torque applications while reducing operator strain.
Comfortable grip handle ensures user control and reduces fatigue during operation.
Professional Click-Type Torque Wrench for Heavy-Duty Applications
Specification |
Details |
|---|---|
Model |
ACTW200 |
Torque Range |
200 – 1000 Nm |
Accuracy |
±4% (EN ISO 6789-1:2017) |
Drive Type |
Square |
Drive Size |
1 inch |
Click Mechanism |
Yes – Audible and Tactile Feedback |
Length |
1254 mm |
Weight |
16.2 kg |
Function |
Manual Torque Application |
Use With |
Stand-alone or with Impact Wrenches |
