CLICK HERE FOR RANGE OF DRILL STEELS
Rock drill type Surface rock drill Hole range 17 mm – 29 mm Weight 15.6 kg Length 575 mm Air consumption 22 l/s Impact rate 2 520 blows/min Revolutions 220 rpm Penetration rate 220 mm/min Hose connection 16 mm Piston diameter 45 mm Stroke length 41 mm Shank Size Available: 19 x 108MM / 22 x 108MM
CLICK HERE FOR PARTS BREAKDOWN
Send Enquiry -
Breaker type Vibro-reduced Weight, incl. hoses 15.5 kg Length 650 mm Oil flow 20 l/min Working pressure 80 bar – 100 bar Back Pressure, max 10 bar Impact rate 2,300 blows/min Vibration level 3 axes (ISO 28927-10) 16.5 m/s² Sound power level guaranteed (2000/14/EC) 105 dB(A) Sound pressure level (ISO 11203) 92 Lp. dB(A) EHTMA class C Shank Size: 22 x 82.5MM
CLICK HERE FOR SPARE PARTS
Send Enquiry -
Breaker type Vibro-reduced Weight, incl. hoses 28 kg Length 735 mm Oil flow 20 – 30 l/min Working pressure 105 bar – 125 bar Back Pressure, max 15 bar Impact rate 1,500 blows/min – 2,100 blows/min Vibration level 3 axes (ISO 28927-10) 4.6 m/s² Sound power level guaranteed (2000/14/EC) 107 dB(A) Sound pressure level (ISO 11203) 95 Lp. dB(A) EHTMA class C/D Shank Sizes Available: 25 x 108mm / 28 x 152mm / 28 x 160mm / 32 x 152mm / 32 x 160mm
CLICK HERE FOR SPARE PARTS
Send Enquiry -
Technical specifications:
Weight (incl. hoses) 13 kg Service Weight 15kg Oil flow 20-40l/min (5.28-10.57 gpm) Max. pressure 172 bar (2,466 psi) Revolutions 2,000-4,000 rpm Speed 42-85 m/s (138-279 ft/s) Disc size 405mm (16 in) Arbor size 25.4mm (1 in) Cutting Depth 160 mm (6.3 in) Cutting Depth when mounting on cart 125 mm (4.9 in) Vibration level 3 axes 4.9 m/s2 Sound power level guaranteed 116 Lw dB(A) Sound pressure level 102 LP, r=1m dB(A) EHTMA class C/D/E Part number 1809 0160 00 Send Enquiry -
Breaker type vibro-reduced Breaker version silenced Weight 37 kg Length 745 mm Air consumption 34 l/s Impact rate 1,200 blows/min Vibration level 3 axes (ISO 28927-10) 5.7 m/s² Sound power level guaranteed (2000/14/EC) 111 Lw. dB(A) Sound pressure level (ISO 11203) 99 Lp. dB(A) Shank size: Hex 28×160 mm – 1 1⁄8 x 61⁄4 inch Part number 8461 0227 01 WORKING TOOLS SHANK 28X160MM / 32 x 160MM
-
P/N: 3083327100 MOIL POINT 380MM WORKING LENGTH
-
P/N: 3083327400 NARROW CHISEL 380MM WORKING LENGTH
-
P/N: 3083327700 WIDE CHISEL TIP 75MM / 380MM WORKING LENGTH
- P/N: 3083327800 NASPHALT CUTTER TIP 125MM / 300MM WORKING LENGTH
CLICK HERE FOR PARTS BREAKDOWN
CLICK HERE FOR MORE INFO ON BREAKERS
Send Enquiry -
-
Breaker type standard Breaker version silenced Weight 37 kg Length 729 mm Air consumption 35 l/s Impact rate 1,200 blows/min Vibration level 3 axes (ISO 28927-10) 19.5 m/s² Sound power level guaranteed (2000/14/EC) N/A Sound pressure level (ISO 11203) N/A Shank size: Hex 32×160 mm – 1 1⁄4 x 61⁄4 inch Part number 8461 0227 23 WORKING TOOLS SHANK 32 x 160MM
-
P/N: 3083327100 MOIL POINT 380MM WORKING LENGTH
-
P/N: 3083327400 NARROW CHISEL 380MM WORKING LENGTH
-
P/N: 3083327700 WIDE CHISEL TIP 75MM / 380MM WORKING LENGTH
- P/N: 3083327800 NASPHALT CUTTER TIP 125MM / 300MM WORKING LENGTH
CLICK HERE FOR MORE INFO ON BREAKERS
Send Enquiry -
-
Breaker type standard Breaker version silenced Weight 42 kg Length 750 mm Air consumption 40 l/s Impact rate 1,110 blows/min Vibration level 3 axes (ISO 28927-10) 4.2 m/s² Sound power level guaranteed (2000/14/EC) 111 Lw Sound pressure level (ISO 11203) 99 Lp Shank size: Hex 28×160 / 32×160 mm Part number 8461 0227 23 WORKING TOOLS SHANK 28 x 160MM / 32 x 160MM
-
P/N: 3083327100 MOIL POINT 380MM WORKING LENGTH
-
P/N: 3083327400 NARROW CHISEL 380MM WORKING LENGTH
-
P/N: 3083327700 WIDE CHISEL TIP 75MM / 380MM WORKING LENGTH
- P/N: 3083327800 NASPHALT CUTTER TIP 125MM / 300MM WORKING LENGTH
CLICK HERE FOR PARTS BREAKDOWN
CLICK HERE FOR MORE INFO ON BREAKERS
Send Enquiry -
-
Breaker type standard Breaker version silenced Weight 33 kg Length 690 mm Air consumption 36 l/s Impact rate 1,500 blows/min Vibration level 3 axes (ISO 28927-10) 16.8 m/s² Sound power level guaranteed (2000/14/EC) 109 Lw. dB(A) Sound pressure level (ISO 11203) 97 Lp. dB(A) Shank size: Hex 32×160 mm – 1 1⁄4 x 61⁄4 inch Part number 8461 0227 23 WORKING TOOLS SHANK 28X160MM / 32 x 160MM
-
P/N: 3083327100 MOIL POINT 380MM WORKING LENGTH
-
P/N: 3083327400 NARROW CHISEL 380MM WORKING LENGTH
-
P/N: 3083327700 WIDE CHISEL TIP 75MM / 380MM WORKING LENGTH
- P/N: 3083327800 NASPHALT CUTTER TIP 125MM / 300MM WORKING LENGTH
CLICK HERE FOR PARTS BREAKDOWN
CLICK HERE FOR MORE INFO ON BREAKERS
Send Enquiry -
-
Breaker type standard Breaker version silenced Weight 43 kg Length 710 mm Air consumption 40 l/s Impact rate 1,260 blows/min Vibration level 3 axes (ISO 28927-10) 15.3 m/s² Sound power level guaranteed (2000/14/EC) 111 Lw Sound pressure level (ISO 11203) 99 Lp Shank size: Hex 28x160mm / 32×160 mm Part number 8461 0227 23 WORKING TOOLS SHANK 28 x 160MM / 32 x 160MM
-
P/N: 3083327100 MOIL POINT 380MM WORKING LENGTH
-
P/N: 3083327400 NARROW CHISEL 380MM WORKING LENGTH
-
P/N: 3083327700 WIDE CHISEL TIP 75MM / 380MM WORKING LENGTH
- P/N: 3083327800 NASPHALT CUTTER TIP 125MM / 300MM WORKING LENGTH
CLICK HERE FOR PARTS BREAKDOWN
CLICK HERE FOR MORE INFO ON BREAKERS
Send Enquiry -
-
Hammer type Standard Hammer version silenced Weight 10 kg Length 500 mm Air consumption 18.5 l/s Impact rate 1,800 blows/min Vibration level 3 axes (ISO 28927-10) 16.1 m/s² Sound power level guaranteed (2000/14/EC) 103 dB(A) Sound pressure level (ISO 11203) 91 Lp. dB(A) Tool retainer cap WORKING TOOLS SHANK 22×82.5MM
- P/N: 3083324200 MOIL POINT 380MM WORKING LENGTH
- P/N: 3083324400 NARROW CHISEL 380MM WORKING LENGTH
- P/N: 3083324600 WIDE CHISEL 75MM TIP 380MM WORKING LENGTH
- P/N: 3083306900 ASPHALT CUTTER 125MM TIP / 380MM WORKING LENGTH
CLICK HERE FOR PARTS BREAKDOWN
CLICK HERE FOR MORE INFO ON CHIPPING HAMMERS
Send Enquiry -
Breaker type vibro-reduced Breaker version silenced Weight 22.5 kg Length 595 mm Air consumption 26 l/s Impact rate 1,500 blows/min Vibration level 3 axes (ISO 28927-10) 3.7 m/s² Sound power level guaranteed (2000/14/EC) 104 Lw. dB(A) Sound pressure level (ISO 11203) 92 Lp. dB(A) Shank size: Hex 25×108 mm – 1 x 41⁄4 inch Part number 8461 0224 31 WORKING TOOLS SHANK 25x108MM / 28x160MM
-
P/N: 3083324200 MOIL POINT 380MM WORKING LENGTH
-
P/N: 3083324400 NARROW CHISEL 380MM WORKING LENGTH
-
P/N: 3083324600 WIDE CHISEL 75MM TIP 380MM WORKING LENGTH
-
P/N: 3083306900 ASPHALT CUTTER 125MM TIP / 380MM WORKING LENGTH
CLICK HERE FOR MORE INFO ON BREAKERS
CLICK HERE FOR PARTS BREAKDOWN
Send Enquiry -
-
Breaker type vibro-reduced Breaker version silenced Weight 21 kg Length 650 mm Air consumption 25 l/s Impact rate 1,140 blows/min Vibration level 3 axes (ISO 28927-10) 7.6 m/s² Sound power level guaranteed (2000/14/EC) 105 Lw. dB(A) Sound pressure level (ISO 11203) 93 Lp. dB(A) Shank size: Hex 25×108 mm – 1 x 41⁄4 inch Part number 8461 0224 22 WORKING TOOLS SHANK 25x108MM
-
P/N: 3083324200 MOIL POINT 380MM WORKING LENGTH
-
P/N: 3083324400 NARROW CHISEL 380MM WORKING LENGTH
-
P/N: 3083324600 WIDE CHISEL 75MM TIP 380MM WORKING LENGTH
-
P/N: 3083306900 ASPHALT CUTTER 125MM TIP / 380MM WORKING LENGTH
CLICK HERE FOR MORE INFO ON BREAKERS
CLICK HERE FOR PARTS BREAKDOWN
Send Enquiry -
-
Hammer type Standard Hammer version silenced Weight 10 kg Length 520 mm Air consumption 17 l/s Impact rate 1,350 blows/min Vibration level 3 axes (ISO 28927-10) 22.4 m/s² Sound power level guaranteed (2000/14/EC) 102 dB(A) Sound pressure level (ISO 11203) 90 Lp. dB(A) Tool retainer cap WORKING TOOLS SHANK 22X82.5MM
CLICK HERE FOR PARTS BREAKDOWN
CLICK HERE FOR MORE INFO ON CHIPPING HAMMERS
Send Enquiry -
Hammer type Standard Hammer version silenced Weight 10.5 kg Length 500 mm Air consumption 17 l/s Impact rate 1,350 blows/min Vibration level 3 axes (ISO 28927-10) 22.4 m/s² Sound power level guaranteed (2000/14/EC) 103 dB(A) Sound pressure level (ISO 11203) 91 Lp. dB(A) Tool retainer kick-latch WORKING TOOLS SHANK 22X82.5MM
CLICK HERE FOR PARTS BREAKDOWN
CLICK HERE FOR MORE INFO ON CHIPPING HAMMERS
Send Enquiry -
Technical Specifications
Spindle thread UNF 3/8″-24 PRO Yes Sound standard ISO15744 Vibration standard ISO28927-5 EC standard ISO 11148-3 EAC certified Yes EU directives 2006/42/EC Send Enquiry -
- Free speed : 750 r/min
- Power : 250 W
- Chuck capacity range max : 13 mm
- Chuck capacity range min : 2 mm
- Length : 248 mm
- Spindle thread : UNF 3/8″-24
- Air consumption at free speed : 10 l/s
- Air inlet thread : 1/4 inch
- Sound standard : ISO15744
- Sound pressure : 85 dB(A)
- Sound uncertainty : 3 dB(A)
- Vibration standard : ISO28927-5
- Vibration value : 3.7 m/s²
- WEEE : 0
- EAC certified : Yes
- EU directives : 2006/42/EC
- EC standard : ISO 11148-3
- PRO : Yes
- Rec hose size : 10 mm
- Sound power : 96 dB(A)
- Vibration uncertainty : 1.2 m/s²
- Weight : 1.45 kg
Send Enquiry -
Technical Specifications Chuck capacity 1.5 – 10 mm Free speed 2400 r/min Weight 0.85 kg Length 234 mm Spindle thread UNF 3/8″-24 Air consumption at free speed 11 l/s Rec hose size 10 mm Power 460 W Air inlet thread BSP 0.25 Sound standard ISO15744 Sound power 91 dB(A) Sound pressure 80 dB(A) Sound uncertainty 3 dB(A) Vibration standard ISO28927-5 Vibration value Obsolete vibration standard ISO8662-1 Send Enquiry -
Technical Specifications Chuck capacity 1.5 – 10 mm Free speed 2000 r/min Weight 1.1 kg Length 242 mm Spindle thread UNF 3/8″-24 Air consumption at free speed 9.3 l/s Rec hose size 10 mm Power 330 W Air inlet thread BSP 0.25 Sound standard ISO15744 Sound pressure 78 dB(A) Sound uncertainty 3 dB(A) Vibration standard ISO28927-5 Vibration value Obsolete vibration standard ISO8662-1 Send Enquiry -
Breaker type Vibro-reduced Weight, incl. hoses 25 kg Length 650 mm Oil flow 20 l/min Working pressure 95 bar – 110 bar Back Pressure, max 10 bar Impact rate 1,400 blows/min Vibration level 3 axes (ISO 28927-10) 5 m/s² Sound power level guaranteed (2000/14/EC) 106 dB(A) Sound pressure level (ISO 11203) 93 Lp. dB(A) EHTMA class C Shank Size: 25 x 108mm / 28 x 152mm / 28 x 160mm / 32 x 152mm / 32 x 160mm
CLICK HERE FOR SPARE PARTS
Send Enquiry -
Breaker type Standard Weight, incl. hoses 22.5 kg Length 690 mm Oil flow 20 l/min – 30 l/min Working pressure 105 bar – 125 bar Back Pressure, max 15 bar Impact rate 1,500 blows/min – 2,100 blows/min Vibration level 3 axes (ISO 28927-10) 16.6 m/s² Sound power level guaranteed (2000/14/EC) 107 dB(A) Sound pressure level (ISO 11203) 95 Lp. dB(A) EHTMA class C/D Shank Sizes Available: 25 x 108mm / 28 x 152mm / 28 x 160mm / 32 x 152mm / 32 x 160mm
CLICK HERE FOR SPARE PARTS
Send Enquiry -
Breaker type Vibro-reduced Weight, incl. hoses 32.5 kg Length 765 mm Oil flow 20 l/min – 30 l/min Working pressure 110 bar – 125 bar Back Pressure, max 15 bar Impact rate 1,350 blows/min – 1,750 blows/min Vibration level 3 axes (ISO 28927-10) 4.6 m/s² Sound power level guaranteed (2000/14/EC) 107 dB(A) Sound pressure level (ISO 11203) 94 Lp. dB(A) EHTMA class C/D Shank Sizes Available: 28 x 152mm / 28 x 160mm / 32 x 152mm / 32 x 160mm
CLICK HERE FOR SPARE PARTS
Send Enquiry -
Breaker type Vibro-reduced Weight, incl. hoses 39 kg Length 765 mm Oil flow 30 l/min – 40 l/min Working pressure 110 bar – 125 bar Back Pressure, max 15 bar Impact rate 1,150 blows/min – 1,600 blows/min Vibration level 3 axes (ISO 28927-10) 5.4 m/s² Sound power level guaranteed (2000/14/EC) 106 dB(A) Sound pressure level (ISO 11203) 93 Lp. dB(A) EHTMA class D/E Shank Sizes Available: 28 x 152mm / 28 x 160mm / 32 x 152mm / 32 x 160mm
CLICK HERE FOR SPARE PARTS
Send Enquiry -
Fuel Petrol Brand Honda Power (kW) 9.6 kW Weight incl. oil 91 kg Dimensions (LxWxH) 745x600x705 mm Oil flow 20 l/min – 30 l/min Maximum pressure 150 bar Fuel capacity 6.5 l Hose included yes Power On Demand (POD) yes Oil control: engine oil yes Electric start no Filtration 25μ filter in return line. Filter by-pass valve in valve block. Cooling system Thermostatically controlled air blast oil cooler. EHTMA class C/D Part number 1807 0110 32 Part number (not sold within EU) 1807 0110 32 Sound power level guaranteed (2000/14/EC) 101 dB(A) Sound pressure level (ISO 11203) 89 Lp. dB(A) CLICK HERE FOR PARTS SHEET
Send Enquiry -
Model LPD-HD-T Activation type By trigger lever Hydraulic system Open centre Service weight kg 45 *3 Oil flow l/min 28-40 Working pressure bar 105-125 Impact rage bpm 1,320 (30 l/min) Post/rod diameters mm 70-150 Vibration level 3 axes (ISO 28927-10) 20lpm *4 m/s² 20.1 Sound power level guaranteed (2000/14/EC) *4 Lw dB(A) 118 Sound pressure level (ISO 11203) *4 Lp, r=1m dB(A) 105 EHTMA class D/E Part number 1801 4140 00 Send Enquiry -
Model LPD-LD-T Activation type By trigger lever Hydraulic system Open centre Service weight kg 18 *1 Oil flow l/min 20 Working pressure bar 80-100 Impact rage bpm 2,300 Post/rod diameters mm Oct-60 Vibration level 3 axes (ISO 28927-10) 20lpm *4 m/s² 17.5 Sound power level guaranteed (2000/14/EC) *4 Lw dB(A) 116 Sound pressure level (ISO 11203) *4 Lp, r=1m dB(A) 102 EHTMA class C Part number 1801 3940 06 Send Enquiry -
Model LPP 10 HD Service weight kg (lb) 60 (132) Oil flow l/min (gpm) 20-40 (5.28-10.57) Working pressure bar (psi) 100-160 (1,450-2,321) Max back pressure bar (psi) 30 (435) Lift capacity per stroke mm (in) 12-200 (0.4-7.8) Pulling force kg (lb) 6.000 (13,228) Full pulling force kg (lb) 10.000 (22,046) EHTMA class C/D/E Part number 1801 8100 03 Send Enquiry -
- Blows : 190 Hz
- Max working pressure : 6.3 bar
- Air consumption : 0.6 l/s
- Air inlet thread BSP : 1/8
- Rec hose size : 3.2 mm
- Weight : 0.12 kg
- Length : 175 mm
- Vibration uncertainty : 1 m/s²
- Vibration value : 5.6 m/s²
- EAC certified : Yes
- EC standard : ISO 11148-4
- EU directives : 2006/42/EC
- Max working pressure : 90 psi
- PRO : Yes
- Sound pressure : 72 dB(A)
- Sound standard : ISO15744
- Sound uncertainty : 3 dB(A)
- UK legislation : S.I. 2008/1597
- UK standard : ISO 11148-4
- Vibration standard : ISO28927-9
Send Enquiry -
- Blows : 40 Hz
- Stroke : 11 mm
- Max working pressure : 6.3 bar
- Piston dia : 0.9 inch
- Piston dia : 23 mm
- Air consumption : 1.9 l/s
- Air inlet thread BSP : 1/4
- Rec hose size : 10 mm
- Rec hose size : 378 inch
- Weight : 2.35 kg
- Weight : 5.2 lb
- Length : 370 mm
- Vibration uncertainty : 0.8 m/s²
- Vibration value : 3.1 m/s²
- Dampening : Vibration-damped
- Air consumption : 4 cfm
- EAC certified : Yes
- EC standard : ISO 11148-4
- EU directives : 2006/42/EC
- Energy per blow : 3 J
- Energy per blow : 2.2 ft lb
- Max working pressure : 90 psi
- PRO : Yes
- Sound power : 96 dB(A)
- Sound pressure : 85 dB(A)
- Sound standard : ISO15744
- Sound uncertainty : 3 dB(A)
- Stroke : 0.43 inch
- UK legislation : S.I. 2008/1597
- UK standard : ISO 11148-4
- Vibration standard : ISO28927-9
Send Enquiry -
Weight 14.1 kg Length 600 mm Air flow 21 l/s Working pressure 95 bar – 110 bar Back Pressure, max 10 bar Impact rate 900 blows/min Vibration level 3 axes (ISO 28927-10) 12.3m/s² Sound power level guaranteed (2000/14/EC) 105 dB(A) Sound pressure level (ISO 11203) 93 Lp. dB(A) CLICK HERE FOR SPARE PARTS LIST
Send Enquiry -
Weight 15.4 kg Length 676 mm Oil flow 21 l/min Working pressure 95 bar – 110 bar Back Pressure, max 10 bar Impact rate 720blows/min Vibration level 3 axes (ISO 28927-10) 14.3m/s² Sound power level guaranteed (2000/14/EC) 105 dB(A) Sound pressure level (ISO 11203) 93 Lp. dB(A) Stroke Long 11″ CLICK HERE FOR SPARE PARTS
